NOIV1SN025KA
Glass Lid
The VITA 25K image sensor uses a glass lid without any
coatings. Figure 39 shows the transmission characteristics
of the glass lid.
As seen in Figure 39, the sensor does not have an infrared
attenuating filter glass. A filter must be provided in the
optical path when color devices are used (source:
http://www.pgo-online.com ).
Figure 39. Transmission Characteristics of Glass Lid
SILICON ERRATA
This section describes the erratum for the VITA 25K
family.
Details include erratum trigger conditions, scope of
impact, available workaround, and silicon revision
applicability.
VITA 25K Qualification Status
Production Silicon
VITA 25K Errata Summary
This table defines how the errata applies to the VITA 25K.
Items
[1]. Higher Standby current than
rated in data sheet
Part Number
VITA 25K family
Silicon revision
Production Silicon
Fix Status
Silicon fix planned
Higher Standby Current
? PROBLEM DEFINITION
In all states except for ‘idle’ and ‘running’ (including
‘reset’) there can be abnormal high power consumption on
vdd_33.
? PARAMETERS AFFECTED
Power
? TRIGGER CONDITION(S)
Entering an affected state (reset, standby(1), standby(2)).
? SCOPE OF IMPACT
High power consumption, not influencing performance
? WORKAROUND
Maintain the device in ‘power-off ’, ‘idle’ or ‘running’
modes.
? FIX STATUS
The cause of this problem and its solution have been
identified. Silicon fix is planned to correct the deficiency.
? COMPLETION DATE
Production silicon with Stand-by current fix is planned.
when grabbing images.
http://onsemi.com
72
